CO Sensor Kit with Arduino Nano - MQ-7 Carbon Monoxide Sensor Project — a beginner-level kit.
CO Sensor Kit with Arduino Nano - Build an MQ-7 Carbon Monoxide Sensor Project
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Carbon monoxide has no smell, which is why homes need certified CO alarms; this kit shows how a CO sensor responds. With this kit, you'll assemble an MQ-7 sensing project that flashes red LEDs and sounds a buzzer when the reading crosses the threshold you set. It is a learning prototype, not a certified safety device; fit a certified CO alarm.
What You'll Build
You'll build the circuit on a breadboard. The MQ-7 sensor continuously samples air quality and sends readings to the Arduino Uno. When the reading passes the limit you calibrate, three red LEDs light up and the buzzer sounds.
What You'll Learn
- How the MQ-7 metal-oxide sensor responds to carbon monoxide
- Reading analog signals and converting them to digital thresholds
- Building circuits on a breadboard without soldering
- Programming conditional logic to control LED and buzzer outputs
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| MQ-7 CO Sensor | 1 |
| Active Buzzer | 1 |
| 5mm Red LED | 3 |
| 220Ω Resistors | 5 |
| 10kΩ Resistors | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 20 |
| 9V Battery Snap | 1 |
Who This Kit Is For
Ideal for CBSE/ICSE students working on science exhibitions, ATL Tinkering Lab innovators, and makers curious about environmental sensors. With a build time of 2-3 hours and zero soldering, it's accessible for beginners as young as 10, guided by an adult, and makes a powerful project for school competitions.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to launch the AI companion for instant step-by-step help, or reach out on WhatsApp-our team responds.
How do I test the circuit?
Lower the threshold in the code until the reading in clean air crosses it, and check that the buzzer and LEDs respond.
Can I install this as a home CO detector?
No. It is a learning project; fit a certified CO alarm.
Does the sensor detect other gases?
The MQ-7 is sensitive to carbon monoxide and, to a lesser extent, hydrogen and LPG. The code can be adjusted to set thresholds only for CO.
MQ-7 CO sensor reading turns on the buzzer and LEDs above your set threshold. LED and buzzer warning.
What's in this kit
- Arduino Uno R3
- MQ-7 CO Sensor
- Active Buzzer
- 5mm Red LED x3
- 220Ω Resistors x5
- 10kΩ Resistors x5
- 400-pt Breadboard
- M-M Wires x20
- 9V Battery Snap
