Earthquake Vibration Logger Kit with ESP32 + MPU6050
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Earthquake Vibration Logger Kit with ESP32 + MPU6050 — a beginner-level kit.
Build an AI Seismometer: Earthquake Vibration Logger Kit with ESP32 & MPU6050
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A shake detector: an MPU6050 sensor feels vibration, and an ESP32-S3 runs a small trained model that tells normal background shaking from a strong shake. Green and red LEDs and the OLED show the state.
What's in the box
- ESP32-S3 Dev Board
- MPU6050
- 0.96in OLED SSD1306
- 5mm Red LED × 2
- 5mm Green LED × 2
- 4.7kΩ Resistors × 5
- 220Ω Resistors × 5
- 100nF Caps × 5
- 400-pt Breadboard
- M-M Wires × 20
- USB-C Cable
Power: USB (cable included).
Skill level: Beginner (3-4 hours, no soldering).
Frequently asked questions
Is it a real seismometer?
No. The MPU6050 is a motion sensor, so treat it as a shake detector for learning.
How does it learn "normal"?
You record calm and shaking samples and train a small model on them.
Can it warn of earthquakes?
No. It reacts to shaking it feels and doesn't predict anything.
Turn your bench into a predictive maintenance lab. This kit gives you everything to build a handheld vibration logger that uses a pre-trained Edge Impulse model on an ESP32-S3. Place it near a DC motor, fan, or conveyor — and watch the AI instantly flag abnormal vibrations with a red LED, while logging clean patterns as healthy with green. It’s seismology made smart, the way factories monitor their machines today.
What You'll Build
You'll assemble a compact sensor node that reads real‑time acceleration from the MPU6050, feeds it into an onboard neural network, and shows the verdict on a bright OLED. The red and green LEDs give a clear go/no‑go signal for any rotating equipment. Use it as a physics project to demonstrate early earthquake detection principles, or as the core of a Smart India Hackathon entry on Industry 4.0 — the build is identical, the narrative is yours.
What You'll Learn
- Capture 3‑axis vibration data with the MPU6050 and pre‑process signals for AI
- Upload and run a pre‑trained Edge Impulse model on the ESP32‑S3 at the edge
- Visualize live accelerometer values and classification results on an SSD1306 OLED display
- Build a real‑world motor fault detection system that mimics industrial condition monitoring
Kit Contents
| Component | Quantity |
|---|---|
| ESP32-S3 Dev Board | 1 |
| MPU6050 | 1 |
| 0.96in OLED SSD1306 | 1 |
| 5mm Red LED | 2 |
| 5mm Green LED | 2 |
| 4.7kΩ Resistors | 5 |
| 220Ω Resistors | 5 |
| 100nF Caps | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 20 |
| USB-C Cable | 1 |
Who This Kit Is For
CBSE students building physics or computer science projects, B.Tech first‑year ECE/EEE aspirants exploring IoT and AI, ATL Tinkering Lab facilitators running machine learning workshops, and anyone preparing for the Smart India Hackathon with an Industry 4.0 theme. The pre‑trained model removes the AI learning curve, so you focus on the application.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
The QR code on the box launches an AI companion that walks you through each step — just point your phone at the circuit and it diagnoses connections. If you still need a human, our WhatsApp team replies in minutes.
Do I need prior AI or coding experience?
No. The Edge Impulse model is pre‑trained and the code is provided. You only need to know how to open the Arduino IDE and upload a sketch. Familiarity with basic electronics (breadboarding, LEDs) helps.
Can this kit detect actual earthquakes?
You can log vibration patterns, but the onboard model is tuned for motor fault frequencies. To attempt seismology, replace the model with one you train on earthquake data using the same Edge Impulse workflow — the hardware is ready for it.
How does the pre‑trained model run on the ESP32‑S3?
The Edge Impulse model is compiled as a TensorFlow Lite Micro library. It processes new accelerometer samples every 100 ms, outputs a normal/abnormal probability, and updates the OLED and LEDs — all locally, no cloud needed.
Seismology — MPU6050 feeds a pre-trained Edge Impulse model on ESP32-S3 that classifies normal vs faulty motor vibration.
