Magnetometer 3D Field Mapper Kit with Arduino Uno + MPU6050
Calibrate and Map 3D Magnetic Fields with Arduino Uno & QMC5883L Kit
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Unlock the invisible world of magnetic fields: assemble a professional 3D magnetometer mapper that reads raw sensor data, applies hard-iron calibration, and renders a live ellipsoidal field map on a 1.8-inch TFT display. Whether you're preparing for a Smart India Hackathon demo, a B.Tech ECE capstone, or deep-diving into sensor fusion algorithms, this kit transforms theory into functioning hardware in about 5-6 hours.
What You'll Build
A fully assembled magnetometer calibration system that rotates the QMC5883L on a 3D sphere and corrects hard-iron distortions. The calibrated output is streamed to the TFT as a real-time ellipsoidal map, with data logged to a microSD card alongside RTC timestamps for analysis.
What You'll Learn
- Hard-iron calibration algorithm implementation for 3-axis magnetometers
- Sensor fusion between MPU6050 gyroscope/accelerometer and QMC5883L magnetometer
- TFT display integration using ST7735 over SPI with Arduino Uno
- Data logging to microSD with DS3231 RTC for time-stamped magnetic field datasets
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| QMC5883L Compass | 1 |
| MPU6050 | 1 |
| 1.8in TFT ST7735 | 1 |
| DS3231 RTC | 1 |
| MicroSD Module | 1 |
| 4.7kΩ Resistors | 5 |
| 100nF Caps | 10 |
| PCB Prototype Board | 2 |
| 9V Battery Snap | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
Engineered for B.Tech ECE/EEE students tackling final-year sensor fusion projects, Smart India Hackathon participants building robotics prototypes, and experienced makers who want a pre-validated 3D magnetometer calibration rig without spending weeks debugging individual parts.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to open the AI companion, or send a message on WhatsApp—our support team will guide you through the exact step, using your kit’s build log.
QMC5883L rotated through 3D sphere and calibrated. TFT shows ellipsoidal field map with hard-iron correction.
