Drawing Robot Kit with Arduino Mega + Stepper

SKU: CDN-KIT-0079-CL Brand: Compoden Category: Electronics > Robotics & Motion > Project Kits
Rs. 4,559.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Drawing Robot Kit with Arduino Mega + Stepper — a intermediate-level build.

Build a Polar Drawing Machine with Arduino Mega, Two NEMA 17 Steppers and A4988 Drivers

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Intermediate Build Time: 4-5 hrs Skill: Stepper motor control and polar coordinates

One stepper motor turns the paper while a second moves the pen in and out from the centre. Together they draw spirals, flowers and patterns in polar coordinates. A small servo lifts and lowers the pen between strokes.

What You'll Build

You wire two NEMA 17 stepper motors to two A4988 driver modules on the breadboard, add the capacitors across the motor supply, and connect everything to the Arduino Mega 2560. The 12 V adapter powers the motors. You build the turntable and the pen arm from your own materials, such as card, wood or 3D-printed parts, using the M3 bolts and nuts. Your sketch converts angle and radius into steps.

What You'll Learn

  • Driving NEMA 17 stepper motors with A4988 drivers
  • Setting the A4988 current limit with the Vref trimmer
  • Converting polar coordinates (angle and radius) into motor steps
  • Lifting a pen with a servo between strokes

Kit Contents

Component Quantity
Arduino Mega 2560 Rev3 1
USB Type A to B Cable (1m) 1
NEMA 17 Stepper Motor - 1.8° Step, 0.45Nm, Bipolar 2
A4988 Stepper Motor Driver Module 2
SG90 9g Micro Servo Motor 1
Capacitor Variety Pack – 6 Values (100nF to 470uF) | 30 Pieces 1
12V 2A DC Power Adapter 1
M3 Bolts and Nuts Set 1
MB102 830-Point Breadboard 1
Dupont Jumper Wire Kit (M-M, M-F, F-F, 20cm, 22AWG) 1

Who This Kit Is For

Makers who like art and maths and are comfortable building a simple mechanism. The electronics are complete; the turntable and pen arm are yours to design.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

Does the kit include the turntable and pen rail?

No. It includes the motors, drivers, servo, power supply, capacitors and fasteners. You make the turntable and pen arm from card, wood or printed parts.

How do I set the current limit?

Measure the voltage on each A4988's Vref trimmer and set it for your motor's rated current before running the motors for long.

Why are there capacitors in the kit?

A capacitor across each driver's motor supply absorbs voltage spikes that can damage the A4988 when the motor supply is connected.

Do you deliver across India?

Yes. We ship Drawing Robot Kit with Arduino Mega + Stepper across India including Delhi, Mumbai, Bangalore, Hyderabad, Chennai, and Pune. Orders ship in 3-7 days.

What payment options are available for Drawing Robot Kit with Arduino Mega + Stepper?

We accept UPI, all major debit and credit cards, and Cash on Delivery (COD) available.

Built and shipped from Compoden, with UPI and cards, plus COD available.

Shipping Information

  • Prepaid Orders: ₹45 for orders up to ₹1,999, FREE shipping above ₹1,999
  • COD Orders: ₹45 shipping for orders up to ₹1,999, FREE shipping above ₹1,999. COD available.
  • Delivery Timeline: Dispatch in 3-7 days, delivery in 2-7 days depending on location

Returns & Warranty

  • 7-Day Return: Manufacturing defects only (approval required)
  • Warranty: 7 days from delivery
  • Non-Returnable: Batteries, consumables, cut wires, clearance items
