Polar Coordinate Drawing Robot Kit with Arduino Uno + NEMA 17 Steppers
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Polar Coordinate Drawing Robot Kit with Arduino Uno + NEMA 17 Steppers — an intermediate-level kit.
Polar Coordinate Drawing Robot: Arduino-Powered CNC Plotter Kit with AI Guidance
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A polar plotter: one NEMA 17 stepper turns the paper while a second slides the pen in and out along a 200mm rail, so every point is an angle and a distance. An Arduino Uno with a CNC shield turns those coordinates into spirals, flowers and patterns on paper.
What's in the box
- Arduino Uno R3
- NEMA 17 Stepper × 2
- A4988 Driver × 2
- CNC Shield V3
- 12V 2A PSU
- 100nF Caps × 5
- M3 Bolts+Nuts × 10
- Linear Rail 200mm
- GT2 Belt 50cm
- 400-pt Breadboard
- M-M Wires × 20
Power: the 12V supply. No batteries needed.
Skill level: Intermediate (4-5 hours).
Frequently asked questions
What are polar coordinates?
A way to place a point by its angle and its distance from the centre, instead of by x and y.
Is the turntable included?
No. Mount a stiff disc of card or acrylic on the stepper.
Do I need to solder?
No.
This kit lets you construct a drawing machine that renders mesmerizing polar coordinate patterns—spirals, rhodonea curves, and geometric mandalas—by precisely rotating a turntable while sliding a pen along a radial arm. Whether you're visualizing trigonometric functions in a math project or creating generative art, the robot turns abstract equations into tangible, repeatable drawings.
What You'll Build
A two-axis polar plotter that uses one NEMA17 stepper to spin the drawing platen and a second to move the pen linearly on a 200mm rail. You'll produce intricate patterns by converting angle and radius coordinates into coordinated motor steps. The final machine holds a pen or marker and draws on paper up to A4 size, controlled by Arduino Uno and G-code commands.
What You'll Learn
- Programming stepper motors with Arduino and A4988 drivers
- Converting polar coordinates (θ, r) to precise motor step counts
- Using CNC Shield V3 with GRBL firmware for smooth motion control
- Generating complex geometric patterns through code logic and mathematical loops
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| NEMA 17 Stepper | 2 |
| A4988 Driver | 2 |
| CNC Shield V3 | 1 |
| 12V 2A PSU | 1 |
| 100nF Caps | 5 |
| M3 Bolts+Nuts | 10 |
| Linear Rail 200mm | 1 |
| GT2 Belt 50cm | 1 |
| 400-pt Breadboard | 1 |
| M-M Wires | 20 |
Who This Kit Is For
Ideal for CBSE students exploring CNC and robotics, B.Tech ECE/EEE mechatronics assignments, and Smart India Hackathon teams building automated drawing tools. ATL Tinkering Lab mentors will find it a ready project for teaching stepper synchronization and polar coordinate transformations. If you've tinkered with Arduino before and want to move from simple LED circuits to real motion control, this intermediate kit bridges the gap.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Our AI companion diagnoses common wiring and code errors instantly. You can also send a photo via WhatsApp and get a human reply.
Can this draw my own custom designs, not just preset patterns?
Yes. The kit accepts custom polar coordinate lists or G-code generated from design software. The AI guide includes examples for converting SVG paths to polar plots.
Do I need a computer with specific software?
Any Windows, Mac, or Linux machine with Arduino IDE and a USB port works. All required libraries and GRBL firmware are included in the companion guide.
What is the maximum drawing size?
The turntable holds up to A4 sheets, and the radial stroke reaches 200mm, so you can fill most of that area with geometric art.
One NEMA17 rotates a turntable while a second slides a pen radially, drawing polar coordinate patterns.
What's in this kit
- Arduino Uno R3
- NEMA 17 Stepper x2
- A4988 Driver x2
- CNC Shield V3
- 12V 2A PSU
- 100nF Caps x5
- M3 Bolts+Nuts x10
- Linear Rail 200mm
- GT2 Belt 50cm
- 400-pt Breadboard
- M-M Wires x20
