Wine Cellar Climate Controller Kit: UNO Q, DHT22, 4 Relays

SKU: CDN-KIT-3349-SLD Brand: Compoden Category: Electronics > AI & Advanced Boards > Project Kits
Rs. 6,700.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Wine Cellar Climate Controller Kit: UNO Q, DHT22, 4 Relays — an intermediate-level kit.

Wine Cellar Climate Controller Kit: UNO Q, DHT22, 4 Relays

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Intermediate Build Time: 4-5 hours Skill: IoT Sensor Integration & Control

Kit at a glance

What you build: A wine cellar controller: the UNO Q's Linux side logs cellar temperature, humidity (DHT22) and pressure (BMP280) in Python, and its microcontroller side switches four relays for a cooler, fan, humidifier and light based on your limits.

What's in the box

  • Arduino UNO Q
  • DHT22
  • BMP280
  • 4-ch Relay Module
  • LM2596 Buck Converter
  • 0.96in OLED
  • 1N4007 Diode × 5
  • 4.7kΩ Resistors × 5
  • 100nF Caps × 10
  • PCB Prototype Board × 2
  • Enclosure Box
  • 5V 3A PSU
  • Soldering Iron
  • Solder Wire

Power: 5V 3A adapter included.

Skill level: Intermediate (5-6 hours).

Frequently asked questions

Can I see the history?

Yes, from the log on the Linux side.

Can it run mains devices?

The relays can, but mains wiring needs a qualified person.

Transform how you monitor and protect your wine collection. This kit lets you build a complete climate monitor that reads temperature, humidity, and atmospheric pressure using industrial-grade sensors, displays live values on an OLED screen, and activates relays to control cooling or heating equipment. All sensor data streams to a Linux machine running Python and a time-series database for historical analysis—turning your wine cellar into a smart, data‑driven environment.

What You'll Build

You'll assemble a fully functional climate monitor that safeguards your wine. The Arduino UNO Q reads Dual DHT22 and BMP280 sensors, updates a crisp 0.96‑inch OLED display, and drives a 4‑channel relay module to maintain stable conditions. A companion Python script (provided) collects Arduino serial output and stores it in a time-series database time‑series database on your Linux host, giving you real‑time dashboards and long‑term trend insights for perfect wine aging.

What You'll Learn

  • Interfacing DHT22 temperature/humidity and BMP280 barometric pressure sensors with Arduino UNO Q
  • Designing a real‑time data pipeline from Arduino serial output to a time-series database on Linux using Python
  • Controlling high‑power appliances safely with a 4‑channel relay module and precision buck converter

Kit Contents

Component Quantity
Arduino UNO Q 1
DHT22 1
BMP280 1
4-ch Relay Module 1
LM2596 Buck Converter 1
0.96in OLED 1
1N4007 Diode 5
4.7kΩ Resistors 5
100nF Caps 10
PCB Prototype Board 2
Enclosure Box 1
5V 3A PSU 1
Soldering Iron 1
Solder Wire 1

Who This Kit Is For

This intermediate kit fits B.Tech ECE/EEE students tackling IoT capstone projects, Smart India Hackathon teams building sensor networks, and tech‑savvy wine enthusiasts who want to automate cellar climate control. It’s also ideal for ATL Tinkering Lab instructors looking to demonstrate real‑world data logging. Basic Arduino familiarity is assumed; you will level up to industrial‑grade monitoring with time‑series databases.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

What if I get stuck during the build?

The AI companion offers step‑by‑step guidance; you can also send a WhatsApp message to our support team for a direct human response.

Do I need a Raspberry Pi or Linux computer for a time-series database?

Yes, the kit includes the sensor and control hardware. You’ll need a Linux system (Raspberry Pi, laptop, or cloud VM) to run the Python data‑logging script and a time-series database—we supply the code and setup guide.

How do I calibrate the sensors for a wine cellar?

The DHT22 and BMP280 are factory‑calibrated. Fine‑tune offsets in the Arduino sketch if needed; the AI companion walks you through testing and adjusting for your cellar’s specific range.

Can this kit control a wine cooler or AC unit?

Yes, the 4‑channel relay module switches loads up to 10A. Connect a wine cooler, heater, or fan—just ensure your appliance stays within the relay’s rating and follow the safety guidelines included.

Choose your assembly option:

  • Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
  • Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
