Manufacturing QC Vision Kit v6 - Build an Emotion-Aware Social Robot with Raspberry Pi 5
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Transform a Raspberry Pi 5 into a social robot that reads human expression. This kit provides all the hardware to build a real-time interactive system: the camera captures facial features for emotion recognition, the I2S microphone picks up spoken queries, and an LLM running on the Pi adapts its response tone based on the detected mood - a hands-on demo of empathetic human-robot interaction.
What You'll Build
You will assemble a compact social robotics module with dual OLED displays for expressive eyes, a high-quality microphone for voice input, and a speaker driven by a dedicated amplifier. The Pi 5 processes camera frames locally to classify emotions (happy, neutral, sad, surprised) and routes that mood tag to an LLM running on the same device. The LLM then adjusts its conversational style - more cheerful, calm, or encouraging - creating a responsive companion that feels genuinely adaptive.
What You'll Learn
- Training and deploying a lightweight emotion recognition model on Raspberry Pi 5 using Pi Camera Module 3
- Integrating I2S audio input with an INMP441 microphone and output through a MAX98357 amplifier
- Running a quantized LLM locally on the Pi 5 with NVMe SSD storage for fast inference
- Mapping detected mood to conversation tone in real-time using a feedback loop
Kit Contents
| Component | Quantity |
|---|---|
| Raspberry Pi 5 4GB | 1 |
| Pi Camera Module 3 | 1 |
| INMP441 I2S Mic | 1 |
| MAX98357 Amp | 1 |
| 3W Speaker | 1 |
| OLED Display 1.3in | 2 |
| NVMe SSD 512GB | 1 |
| Pi 5 M.2 HAT+ | 1 |
| USB-C PSU | 1 |
| M-M Wires | 15 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
Ideal for CBSE Class 11-12 students building AI-based emotion detection projects, B.Tech ECE/EEE undergraduates prototyping human-robot interaction theses, Smart India Hackathon participants needing a reliable hardware stack, ATL tinkering labs exploring social robotics, and IIT/NIT/VIT/BITS makers who want a ready-to-use kit for competitions. The intermediate build level assumes you have basic Python and Linux familiarity.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code included in the box to launch the AI companion. It walks you through wiring, code setup, and troubleshooting. You can also message us on WhatsApp for human help within 6 hours.
Does this kit require any soldering or special tools?
No soldering is needed. The provided M-M wires connect all modules via the Pi's GPIO header; you only need a microSD card (not included) to flash the OS.
Can I use this kit for a Smart India Hackathon project?
Absolutely. The emotion recognition and LLM pipeline runs entirely on the edge (no cloud dependency), making it ideal for hackathon demos where connectivity may be limited. The kit's compact footprint and clear documentation let you integrate it quickly.
Is the LLM cloud-based or does it run locally on the Pi 5?
The LLM runs locally on the Raspberry Pi 5 using the NVMe SSD for model storage and fast inference. No internet connection is required after initial setup, keeping all data private and latency low.
Manufacturing QC - Emotion recognition and LLM on Pi 5 detect user mood and adapt conversation tone - social robotics interaction demo.
What's in this kit
- Raspberry Pi 5 4GB
- Pi Camera Module 3
- INMP441 I2S Mic
- MAX98357 Amp
- 3W Speaker
- OLED Display 1.3in x2
- NVMe SSD 512GB
- Pi 5 M.2 HAT+
- USB-C PSU
- M-M Wires x15
