Edge AI Gesture Badge Kit: ESP32-S3, MPU6050, LiPo
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Edge AI Gesture Badge Kit: ESP32-S3, MPU6050, LiPo — an intermediate-level kit.
Edge AI Gesture Badge Kit: ESP32-S3, MPU6050, LiPo
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A wearable edge AI badge: an ESP32-S3 with an MPU6050 classifies gestures on the board and shows each one on a 0.96-inch OLED. It runs from a small LiPo charged by a TP4056 and fits in a badge holder.
What's in the box
- ESP32-S3 Dev Board
- MPU6050
- 0.96in OLED
- 3.7V LiPo 500mAh
- TP4056 Module
- 4.7kΩ Resistors × 5
- 100nF Caps × 5
- PCB Prototype Board × 2
- Lanyard Badge Holder
- Soldering Iron
- Solder Wire
Power: 500mAh LiPo included, charged over USB through the TP4056.
Skill level: Intermediate (4-5 hours).
Frequently asked questions
What gestures can it learn?
Any you record enough examples of, such as a tap, shake or tilt.
How long does the battery last?
It depends on how often it runs the model; expect hours, not days.
You’ll assemble a shirt-pocket AI badge that learns your hand movements—a wave, a thumbs-up, a fist—and shows the recognized gesture on a bright OLED screen. Powered by an ESP32-S3 running a neural network trained with a TinyML training tool, this wearable reads motion data from the MPU6050 accelerometer-gyroscope. Clip it to the included lanyard and demo real-time edge AI at your next school science exhibition or hackathon.
What You'll Build
A personalized AI badge that classifies three custom gestures, a rechargeable device that runs for hours on a 500mAh LiPo cell, and a reprogrammable TinyML platform you can extend to new gestures or applications right from your pocket.
What You'll Learn
- Training a motion classifier using a TinyML training tool and exporting a quantized model
- Deploying TinyML on an ESP32-S3 for real-time inference
- Reading and calibrating 6-axis IMU data from the MPU6050 over I2C
- Assembling a compact wearable with soldering, OLED integration, and LiPo power management
Kit Contents
| Component | Quantity |
|---|---|
| ESP32-S3 Dev Board | 1 |
| MPU6050 | 1 |
| 0.96in OLED | 1 |
| 3.7V LiPo 500mAh | 1 |
| TP4056 Module | 1 |
| 4.7kΩ Resistors | 5 |
| 100nF Caps | 5 |
| PCB Prototype Board | 2 |
| Lanyard Badge Holder | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Who This Kit Is For
CBSE students building AI practicals, B.Tech ECE/EEE undergraduates prototyping for Smart India Hackathon, and ATL Tinkering Lab teams eager to learn edge inference. Also perfect for NIT, VIT, or BITS Pilani students who need a wearable TinyML demo that stands out.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to chat with our AI companion, which walks you through each soldering joint and code upload. For extra help, message us on WhatsApp.
Do I need experience with TinyML tools?
None required. The kit provides pre-trained gesture models and a step-by-step guide; you can also remix the project and train your own gestures on a free online TinyML training tool.
Can I use this badge in a science exhibition or hackathon?
Yes, it’s an ideal Smart India Hackathon hardware entry or CBSE AI project. The wearable form factor and real-time classification grab attention instantly.
Is soldering required?
You’ll solder the MPU6050, OLED, and supporting components onto the prototype boards. The included soldering iron and wire, along with the AI companion’s soldering tips, make it approachable even if you’ve never soldered before.
TinyML model on ESP32-S3 classifies gestures from MPU6050. OLED shows class. Fits in shirt pocket.
What's in this kit
- ESP32-S3 Dev Board
- MPU6050
- 0.96in OLED
- 3.7V LiPo 500mAh
- TP4056 Module
- 4.7kΩ Resistors x5
- 100nF Caps x5
- PCB Prototype Board x2
- Lanyard Badge Holder
- Soldering Iron
- Solder Wire
Choose your assembly option:
- Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
- Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
