Garage Smoke Alarm Kit
Garage Smoke Alarm Kit – Dual ESP8266 IoT Fire Monitoring System
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Imagine a single sensor triggering a silent alert before your garage fills with smoke, logging temperature, humidity, pressure, and smoke concentration to a live dashboard on your laptop. This kit lets you build exactly that: two ESP8266 nodes that publish environmental data to an MQTT broker, which Node-RED visualizes with real-time charts and historical logs. Perfect for a car garage, workshop, or college IoT project where early fire detection is critical.
What You'll Build
A fully functional two-node wireless monitoring network: one node with DHT22 and BMP280 for ambient conditions, another with an MQ-2 smoke sensor and OLED display. Both transmit via MQTT to a broker on your laptop, where Node-RED plots temperature, humidity, pressure, and smoke level over time, and triggers a visual alarm when smoke thresholds are crossed.
What You'll Learn
- Configuring ESP8266 as MQTT clients with ArduinoJson payloads
- Setting up Mosquitto MQTT broker and Node-RED flows
- Calibrating the MQ-2 smoke sensor for early garage fire detection
- Integrating multiple sensors (DHT22, BMP280, OLED) into a single node’s code
Kit Contents
| Component | Quantity |
|---|---|
| ESP8266 NodeMCU | 2 |
| DHT22 Temperature & Humidity Sensor | 2 |
| BMP280 Barometric Pressure Sensor | 1 |
| MQ-2 Smoke/Gas Sensor | 1 |
| 0.96″ OLED Display | 2 |
| LM2596 Buck Converter | 1 |
| 10kΩ Resistors | 10 |
| 4.7kΩ Resistors | 10 |
| 100nF Ceramic Capacitors | 10 |
| 100µF 16V Electrolytic Capacitors | 5 |
| PCB Prototype Board | 2 |
| 830-pt Breadboard | 1 |
| M-M Jumper Wires | 30 |
| Micro USB Cable | 2 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
Engineering students (B.Tech ECE/EEE) building IoT-based fire safety capstone projects, Smart India Hackathon participants prototyping industrial monitoring solutions, and final-year B.Tech/B.E. students from IITs, NITs, VIT, or BITS Pilani who need a ready-to-deploy wireless sensor network for their major project. Also suited for ATL Tinkering Lab mentors demonstrating MQTT data pipelines.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Open the AI companion from the QR code and describe the issue; you’ll get instant troubleshooting steps. If you still need help, WhatsApp our support team for real-time guidance.
Can I connect the dashboard to a cloud platform instead of my laptop?
Yes, the Node-RED flow can be extended to forward data to platforms like ThingSpeak or Adafruit IO. The AI companion includes examples for cloud integration once the local broker is working.
Do I need soldering equipment?
Basic soldering is required to assemble the two nodes on the PCB prototype boards. The included breadboard is for initial prototyping, but the final build demands soldered connections for reliability in a garage environment.
How quickly will I see live data on the dashboard?
The step-by-step guide walks you through MQTT and Node-RED setup; you’ll see data flowing within 2-3 hours. Completing the full permanent build, including soldering and mounting, takes the full 5-6 hours.
Garage Fire — Two ESP8266 nodes publish to MQTT broker. Node-RED on laptop shows live dashboard with historical charts.
What's in this kit
- ESP8266 NodeMCU x2
- DHT22 x2
- BMP280
- MQ-2
- 0.96in OLED x2
- LM2596 Buck Converter
- 10kΩ Resistors x10
- 4.7kΩ Resistors x10
- 100nF Caps x10
- 100µF 16V Caps x5
- PCB Prototype Board x2
- 830-pt Breadboard
- M-M Wires x30
- Micro USB Cable x2
Choose your assembly option:
- Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
- Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
Shipping Information
- Prepaid Orders: ₹75 for orders up to ₹999, FREE shipping above ₹999
- COD Orders: ₹125 shipping + ₹50 COD fee = ₹175 total
- Delivery Timeline: Dispatch in 1-2 days, delivery in 2-7 days depending on location
Returns & Warranty
- 7-Day Return: Manufacturing defects only (approval required)
- Warranty: 7 days from delivery
- Non-Returnable: Batteries, consumables, cut wires, clearance items
