Block-Stacking Robot Arm Kit with Raspberry Pi 5 + Pi Camera Module 3
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Block-Stacking Robot Arm Kit with Raspberry Pi 5 + Pi Camera Module 3 — an intermediate-level kit.
Block-Stacking Robot Arm Kit with Raspberry Pi 5 + Pi Camera Module 3 – AI Robotics with Raspberry Pi 5
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Construct a miniature smart retail system. A Raspberry Pi 5 with camera tracks foam blocks; a 4-axis robotic arm picks and stacks them in order, with error recovery if a block is misplaced. It blends OpenCV, inverse kinematics, and real-time error handling, all running on a Pi 5 with NVMe SSD.
What You'll Build
You will assemble a robot arm on a stable base, wire the servo driver and camera, and load the pre-configured SD card image onto the NVMe drive. The system uses the Pi Camera Module 3 to identify block color and position, then calculates arm trajectories to stack them in a tower sequence you define. If a block tumbles or the tower shifts, the camera re-scans and the arm replans the stacking order. The final setup mimics a retail store counting and reorganizing stock based on foot traffic patterns.
What You'll Learn
- Setting up Raspberry Pi 5 with an NVMe SSD and M.2 HAT for high-speed I/O
- Capturing and processing images with Pi Camera Module 3 via libcamera and OpenCV
- Programming servo movements through the PCA9685 driver to achieve precise robotic arm control
- Implementing error recovery logic: real-time image comparison to detect misplaced blocks and replan arm actions
Kit Contents
| Component | Quantity |
|---|---|
| Raspberry Pi 5 4GB | 1 |
| Pi Camera Module 3 | 1 |
| Servo Driver PCA9685 | 1 |
| MG996R Servo | 4 |
| Robot Arm Kit | 1 |
| Foam Blocks | 20 |
| NVMe SSD 256GB | 1 |
| Pi 5 M.2 HAT+ | 1 |
| USB-C PSU | 1 |
| M-M Wires | 20 |
Who This Kit Is For
Ideal for B.Tech ECE and CS students preparing for Smart India Hackathon
Retail Analytics — Computer vision on Pi 5 identifies block positions — robot arm stacks blocks in planned tower sequence with error recovery.
What's in this kit
- Raspberry Pi 5 4GB
- Pi Camera Module 3
- Servo Driver PCA9685
- MG996R Servo x4
- Robot Arm Kit
- Foam Blocks (not included, use your own)x20
- NVMe SSD 256GB
- Pi 5 M.2 HAT+
- USB-C PSU
- M-M Wires x20
