Demand Response Load-Shedding Node Kit: ESP32, PZEM-004T
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Demand Response Load-Shedding Node Kit: ESP32, PZEM-004T — an advanced-level kit.
Demand Response Load-Shedding Node Kit: ESP32, PZEM-004T
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A demand-response node: a PZEM-004T meter measures a circuit's power, and an ESP32 receives peak-demand signals over MQTT from your own server and switches off non-essential loads through relays at those times, logging every event to microSD.
What's in the box
- ESP32 Dev Board
- PZEM-004T
- 4-ch Relay Module
- DS3231 RTC
- MicroSD Module
- LM2596 Buck Converter
- 0.96in OLED
- 100nF Caps × 10
- PCB Prototype Board × 2
- DIN Rail Enclosure
- 12V 3A PSU
- Soldering Iron
- Solder Wire
Power: 12V 3A adapter included.
Skill level: Advanced (8-10 hours).
Frequently asked questions
Does it connect to my electricity company?
No. It takes signals from your own MQTT server.
Is the PZEM-004T safe to fit?
Mains wiring must be done by a qualified electrician.
Mains wiring must be done by a qualified electrician.
This ESP32-based system demonstrates real-world demand response for grid flexibility. With all components pretested as a coordinated system, you skip the headache of cross-checking voltage levels, firmware libraries, and signal timing yourself.
What You'll Build
When a demand flexibility signal arrives, the relay module disconnects prescheduled loads, recording the event precisely. You end up with a ready-to-demonstrate model perfect for smart grid projects, hackathons, or B.Tech final year submissions.
What You'll Learn
- Program ESP32 to subscribe to MQTT topics for utility demand response commands
- Calibrate PZEM-004T for accurate energy monitoring and log data with DS3231 RTC timestamps
- Implement load shedding logic based on real-time cloud signals using a 4-channel relay
- Design a compact, DIN-rail-mountable industrial prototype with LM2596 buck converter power management
Kit Contents
| Component | Quantity |
|---|---|
| ESP32 Dev Board | 1 |
| PZEM-004T | 1 |
| 4-ch Relay Module | 1 |
| DS3231 RTC | 1 |
| MicroSD Module | 1 |
| LM2596 Buck Converter | 1 |
| 0.96in OLED | 1 |
| 100nF Caps | 10 |
| PCB Prototype Board | 2 |
| DIN Rail Enclosure | 1 |
| 12V 3A PSU | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Who This Kit Is For
Ideal for B.Tech ECE/EEE students working on demand response or smart grid capstone projects. Perfect for Smart India Hackathon teams tackling energy management themes and ATL Tinkering Lab mentors exploring IoT-based utility communication. Also suits early-stage energy startups prototyping demand flexibility hardware.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code and start a chat with the AI companion that has step-by-step knowledge of this kit. If you need human help, reach us on WhatsApp for direct support.
Can I interface this node with my own MQTT broker?
Yes, you can reconfigure the ESP32 to connect to any MQTT broker endpoint. The AI companion guides you through modifying the sketch with your credentials and topic structure.
Does the kit include the actual cloud service or just the hardware?
The kit provides hardware and preloaded code templates that connect to a public MQTT test broker.
Is this kit suitable for monitoring three-phase loads?
The included PZEM-004T measures single-phase AC. For three-phase, you would need additional sensors, but the load-shedding logic remains the same—the AI companion can suggest scaling strategies.
