Gym Equipment Vibration Checker Kit: ESP32-S3, MPU6050
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Gym Equipment Vibration Checker Kit: ESP32-S3, MPU6050 — a beginner-level kit.
Gym Equipment Vibration Checker Kit: ESP32-S3, MPU6050
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A gym equipment vibration checker: clip an MPU6050 to a treadmill or exercise bike motor, and a pre-trained model on an ESP32-S3 classifies the vibration as normal or faulty, with green and red LEDs and the label on the OLED.
What's in the box
- ESP32-S3 Dev Board
- MPU6050
- 0.96in OLED SSD1306
- 5mm Red LED × 2
- 5mm Green LED × 2
- 4.7kΩ Resistors × 5
- 220Ω Resistors × 5
- 100nF Caps × 5
- 400-pt Breadboard
- M-M Wires × 20
- USB-C Cable
Power: USB-C. A USB charger is not included.
Skill level: Intermediate (3-4 hours).
Frequently asked questions
Is it safe on a running machine?
Mount it firmly and keep wires clear of moving parts.
Can I retrain it?
Yes, on your own machine's vibration.
Every spin of a treadmill motor tells a story — and now you can teach an ESP32 to read it. This kit turns a standard MPU6050 accelerometer into a self-contained vibration classifier that distinguishes normal hum from the early rumble of a failing bearing. You'll mount the sensor on any gym machine, acquire live motion data, and let the on-device TinyML model decide: green LED for smooth operation, red LED and an OLED warning when trouble is brewing. It's a real-world AI project that moves the smart factory concept right into your school's sports room.
What You'll Build
You'll assemble a compact monitoring module around the ESP32-S3 Dev Board and MPU6050, wire the OLED and status LEDs, then flash a pre-trained TinyML model that instantly classifies vibration signatures. The system powers over USB, reads acceleration every 20 ms, and updates the OLED with classification confidence. It’s a complete edge AI pipeline — from sensor to insight — that you can deploy on treadmills, exercise bikes, or even a cricket bowling machine.
What You'll Learn
- Capture high-frequency vibration data from an MPU6050 and label it for normal vs. faulty patterns
- Train and export a binary classifier directly in TinyML without writing complex ML code
- Deploy a TinyML model on an ESP32-S3 and run inferences entirely on-device
- Visualize real-time classification results on an SSD1306 OLED display alongside LED indicators
Kit Contents
| Component | Quantity |
|---|---|
| ESP32-S3 Dev Board | x1 |
| MPU6050 | x1 |
| 0.96in OLED SSD1306 | x1 |
| 5mm Red LED | x2 |
| 5mm Green LED | x2 |
| 4.7kΩ Resistors | x5 |
| 220Ω Resistors | x5 |
| 100nF Caps | x5 |
| 400-pt Breadboard | x1 |
| M-M Wires | x20 |
| USB-C Cable | x1 |
Who This Kit Is For
CBSE students exploring AI and IoT will find a ready-made investigatory project that aligns with the new skill subjects. B.Tech ECE and EEE undergraduates can prototype a predictive maintenance system for gym equipment or Smart India Hackathon ideas. ATL Tinkering Labs and IIT/NIT/VIT/BITS clubs looking for an AI+hardware workshop module will appreciate the structured on-ramp to TinyML and sensor fusion — no prior ML experience assumed.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to open the AI companion, which walks through each step with diagrams and code snippets. For complex debugging, send a WhatsApp message or photo — our team responds.
Can I retrain the model for a different machine, like a cricket bowling machine?
Absolutely. The TinyML project is included, so you can record new vibration data from any motor, relabel it, and retrain the classifier — all through the free TinyML account you create during the build.
Do I need prior coding experience with Python or ML?
The kit assumes basic familiarity with Arduino IDE, but the AI companion provides pre-written code and the TinyML workflow is entirely visual. You'll complete the project even if you've never trained a model before.
Can I integrate this with a phone dashboard app or cloud dashboards?
Yes. The ESP32-S3 already connects to Wi‑Fi, and you can extend the firmware to send classification results to a phone dashboard app web dashboard or an IoT platform — the AI companion provides optional extension guides.
Sports — MPU6050 feeds a pre-trained TinyML model on ESP32-S3 that classifies normal vs faulty motor vibration.
What's in this kit
- ESP32-S3 Dev Board
- MPU6050
- 0.96in OLED SSD1306
- 5mm Red LED x2
- 5mm Green LED x2
- 4.7kΩ Resistors x5
- 220Ω Resistors x5
- 100nF Caps x5
- 400-pt Breadboard
- M-M Wires x20
- USB-C Cable
Other projects you can build
Shipping Information
- Prepaid Orders: ₹45 for orders up to ₹1,999, FREE shipping above ₹1,999
- COD Orders: ₹45 shipping for orders up to ₹1,999, FREE shipping above ₹1,999. COD available.
- Delivery Timeline: Dispatch in 3-7 days, delivery in 2-7 days depending on location
Returns & Warranty
- 7-Day Return: Manufacturing defects only (approval required)
- Warranty: 7 days from delivery
- Non-Returnable: Batteries, consumables, cut wires, clearance items
