Water Tank Level Monitor Pro Kit with Arduino Uno

SKU: CDN-KIT-3388-CL Brand: Compoden Category: Electronics > Sensor Starter Kits > Project Kits
Rs. 750.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Water Tank Level Monitor Pro Kit with Arduino Uno — a beginner-level kit.

Water Tank Level Monitor Kit with Arduino Uno – Never Run Dry or Overflow

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Beginner Build Time: 2-3 hrs Skill: Ultrasonic distance sensing and LCD data display

Kit at a glance

What you build: A tank level gauge: an HC-SR04 ultrasonic sensor in the lid measures down to the water, and an Arduino Uno shows the level as a bar graph and in centimetres on a 16x2 LCD. Simple, stand-alone and Wi-Fi-free.

What's in the box

  • Arduino Uno R3
  • HC-SR04 Ultrasonic
  • 16x2 LCD
  • I2C Backpack
  • 10kΩ Resistors × 5
  • 400-pt Breadboard
  • M-M Wires × 20
  • 9V Battery Snap

Power: 9V battery, not included.

Skill level: Beginner (2-3 hours).

Frequently asked questions

How deep a tank can it measure?

The HC-SR04 is rated 2cm to 400cm (ElecFreaks datasheet).

How does it get the level?

It measures the empty space above the water and subtracts that from the tank depth.

Do I need to solder?

No, unless the I2C backpack needs fitting.

Stop guessing whether your overhead tank is full or empty. This kit lets you build a real-time water level monitor that uses ultrasonic pulses to measure from 2cm to 400cm, then displays the depth in both centimetres and inches on an LCD screen — complete with a live bar graph. It’s the exact project thousands of Indian engineering students build for their final-year demonstrations, now in your hands as a pre-tested, beginner-friendly kit.

What You'll Build

A fully functional water level monitor that reads your tank’s height, updates the reading multiple times per second, and shows it on the LCD as numeric values plus a bar that moves left to right as the water level changes. You can mount the ultrasonic sensor at the top of any tank — overhead, sump, or even a rainwater barrel — and get accurate distance readings instantly.

What You'll Learn
