Quiz Buzzer Kit with BC547 Transistor Latch Circuit — a beginner-level build.

Build a Quiz Buzzer with BC547 Transistor Latches, LEDs and an Active Buzzer

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Beginner Build Time: 45 min Skill: Transistor latching circuits

Press a button and your LED lights and the buzzer beeps, and both stay on until the quizmaster resets them. There is no microcontroller and no code: two BC547 transistors wired as a latch remember the press, all on a breadboard powered by three AA batteries (4.5 V).

What You'll Build

Using the BC547 transistors, resistors and tactile buttons, you build a latch for each player on the breadboard: a press turns one transistor on, which holds the other on, so the LED stays lit after the button is released. The active buzzer module beeps when a latch fires: it has its own oscillator, so a steady voltage from the latch is enough to make it sound. A reset button, or the switch on the battery holder, clears it for the next question.

What You'll Learn

  • How an NPN transistor works as a switch
  • How two transistors form a latch that remembers a press
  • Choosing base and LED resistors
  • Reading and building a circuit from a schematic

Kit Contents

Component Quantity
6mm Tactile Push Button Pack (10) x1
BC547 NPN Transistor x4
Active Buzzer Module 3-5V 85dB x1
5mm LED Assorted Pack (Red, Green, Blue, Yellow, White) x1
Resistor Variety Pack - 10 Values, 1/4W Carbon Film x1
400-point solderless breadboard x1
AA Battery Holder with Switch x1
AA Alkaline Battery 1.5V x3
Dupont Jumper Wire Kit (M-M, M-F, F-F, 20cm, 22AWG) x1

Who This Kit Is For

Beginners who want to understand electronics without a microcontroller, classrooms running quizzes and anyone curious about how memory can be made from transistors.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

How many players can it support?

Four BC547 transistors make two two-transistor latches, so two players as supplied. More transistors add more players.

Does it need programming?

No. It is a pure transistor circuit with no code.

Why does the LED stay on after I let go?

The latch feeds the output back to the input, so the circuit holds its state until it is reset.

Why three AA batteries instead of a 9 V battery?

The active buzzer module is rated 3-5 V, so the kit runs from three AA cells (4.5 V) in a holder with an on/off switch. The transistor latches and LEDs work at 4.5 V too.
