MQ-2 + MQ-7 Gas Sensor Learning Panel Kit: Arduino Uno, TFT — an intermediate-level kit.
MQ-2 + MQ-7 Gas Sensor Learning Panel Kit: Arduino Uno, TFT
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A two-gas sensor learning panel: an MQ-2 (smoke and LPG) and an MQ-7 (carbon monoxide) feed an Arduino Uno that shows both readings on a 1.8-inch TFT with zones you set, and sounds a buzzer and red LEDs above your threshold.
What's in the box
- Arduino Uno R3
- MQ-2 Gas Sensor
- MQ-7 CO Sensor
- 1.8in TFT ST7735
- Active Buzzer
- 5mm Red LED × 3
- 220Ω Resistors × 5
- 10kΩ Resistors × 10
- 100nF Caps × 5
- 400-pt Breadboard
- M-M Wires × 25
- 9V Battery Snap
Power: 9V battery, not included. Two MQ heaters drain a 9V battery fast; use a 5V adapter.
Skill level: Intermediate (3-4 hours).
Frequently asked questions
Can I use it as a gas or CO alarm?
No. This is a learning project, not a gas or CO alarm. Fit certified detectors.
Why does the MQ-7 need special timing?
It reads CO accurately only with its heater cycled between high and low voltage.
What You'll Build
When a reading passes your threshold, the buzzer and red LEDs turn on.
What You'll Learn
- Read analog sensor data from MQ-2 and MQ-7 gas sensors
- Calibrate gas sensors for indoor air quality monitoring
- Program a TFT display to show multi-parameter readings with shaded thresholds
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | x1 |
| MQ-2 Gas Sensor | x1 |
| MQ-7 CO Sensor | x1 |
| 1.8in TFT ST7735 | x1 |
| Active Buzzer | x1 |
| 5mm Red LED | x3 |
| 220Ω Resistors | x5 |
| 10kΩ Resistors | x10 |
| 100nF Caps | x5 |
| 400-pt Breadboard | x1 |
| M-M Wires | x25 |
| 9V Battery Snap | x1 |
Who This Kit Is For
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code on the box to chat with our AI companion trained on this exact kit. If you need human help, message us on WhatsApp for step-by-step guidance.
Can I log the gas readings over time?
The Arduino Uno can send serial data to a computer for logging via the USB port. With minor code modifications, you can log to an SD card module (not included). The AI companion can help you add data logging.
What power does it need?
The kit includes a 9V battery snap, so you can power the panel with a 9V battery for portable use. It can also be powered via the Arduino Uno’s USB port from a power bank or laptop.
MQ-2 and MQ-7 together monitor both smoke/LPG and carbon monoxide.
