Smoke + CO Sensor Lab Kit: Arduino Uno, MQ-2, MQ-7, TFT
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Smoke + CO Sensor Lab Kit: Arduino Uno, MQ-2, MQ-7, TFT — an intermediate-level kit.
Smoke + CO Sensor Lab Kit: Arduino Uno, MQ-2, MQ-7, TFT
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
A learning project, not a certified gas, smoke, fire or CO alarm. Fit a certified alarm to protect people or property.
Kit at a glance
What you build: A two-gas sensor lab: an MQ-2 (smoke and LPG) and an MQ-7 (carbon monoxide) feed an Arduino Uno that graphs both readings over time on a 1.8-inch TFT, so you can compare how each sensor responds and warms up. A buzzer and red LEDs mark your test thresholds.
What's in the box
- Arduino Uno R3
- MQ-2 Gas Sensor
- MQ-7 CO Sensor
- 1.8in TFT ST7735
- Active Buzzer
- 5mm Red LED × 3
- 220Ω Resistors × 5
- 10kΩ Resistors × 10
- 100nF Caps × 5
- 400-pt Breadboard
- M-M Wires × 25
- 9V Battery Snap
What You'll Build
A two-gas sensor lab: an MQ-2 (smoke and LPG) and an MQ-7 (carbon monoxide) feed an Arduino Uno that graphs both readings over time on a 1.8-inch TFT, so you can compare how each sensor responds and warms up. A buzzer and red LEDs mark your test thresholds.
What You'll Learn
- Interface MQ-2 and MQ-7 gas sensors with Arduino to read analog gas concentrations
- Process sensor data to calculate parts-per-million (PPM) for smoke, LPG, and CO
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | x1 |
| MQ-2 Gas Sensor | x1 |
| MQ-7 CO Sensor | x1 |
| 1.8in TFT ST7735 | x1 |
| Active Buzzer | x1 |
| 5mm Red LED | x3 |
| 220Ω Resistors | x5 |
| 10kΩ Resistors | x10 |
| 100nF Caps | x5 |
| 400-pt Breadboard | x1 |
| M-M Wires | x25 |
| 9V Battery Snap | x1 |
Who This Kit Is For
If you want to move beyond beginner blink circuits and tackle a multi-sensor alert system, this kit delivers a solid foundation.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code on the box to chat with the AI build companion trained on this exact kit, or message us on WhatsApp for direct support from our team.
Can the kit detect both LPG and carbon monoxide at the same time?
Yes, the MQ-2 sensor monitors combustible gases (LPG, smoke) while the MQ-7 handles carbon monoxide.
Do I need to solder anything?
No soldering required. All connections use the breadboard and male-male jumper wires. The kit is fully plug-and-play for quick prototyping.
