AVR ISP Shield PCB for Arduino UNO Bootloader Programmer

This PCB is an ISP programmer shield for the Arduino UNO that lets you burn bootloaders onto AVR microcontrollers. It eliminates messy breadboard wiring and provides a plug-and-play solution for programming ATmega328P, ATmega168, and similar chips. Use it to revive chips, build custom Arduino boards, or mass-program bootloaders.

Key Specifications

Specification Value
Dimensions 53.4 mm x 53.4 mm (standard Arduino shield size)
Compatible Microcontrollers ATmega328P, ATmega168, ATtiny85 (with adapter), ATmega32U4
ISP Header Standard 6-pin ICSP (2×3)
Power Jumper Selectable 5V or 3.3V target power
Board Compatibility Arduino UNO R3 form factor

What You Can Build With This

  • Burn bootloader on a new ATmega328P chip to use as a standalone Arduino
  • Revive a bricked Arduino board by reflashing its bootloader
  • Program ATtiny85 microcontrollers using an adapter
  • Build your own Arduino-compatible board from scratch

Compatibility

This shield fits directly onto an Arduino UNO R3 board. It supports AVR microcontrollers with 6-pin ICSP interface, including ATmega328P, ATmega168, and ATmega32U4. Use with 5V boards; the selectable power jumper provides 5V or 3.3V output for the target chip. Works with the Arduino IDE’s ‘Arduino as ISP’ sketch.

Wiring Notes

Insert the shield onto Arduino UNO headers, connect target chip via ICSP cable (MOSI, MISO, SCK, RESET, VCC, GND). Ensure correct orientation; use the jumper to match target voltage. No external power supply is needed for 5V targets.

Is this compatible with Arduino Mega?

The shield is designed for the Arduino UNO R3 form factor; it may not fit Mega directly but can be used with jumper wires.

Do I need to solder the ISP header?

This is a bare PCB; you need to solder the header pins and components (resistors, LED, etc.) as per the included schematic.

Does this include the ATmega chip?

No, the chip is not included. This is only the PCB to build the programmer shield.
