Sensor Overlay Camera Kit: ESP32-S3, OV2640, ILI9341 TFT

SKU: CDN-KIT-2075-SLD Brand: Compoden Category: Electronics > Data & Visualization > Project Kits
Rs. 3,640.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Sensor Overlay Camera Kit: ESP32-S3, OV2640, ILI9341 TFT — an advanced-level kit.

Sensor Overlay Camera Kit: ESP32-S3, OV2640, ILI9341 TFT

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Advanced Build Time: 6-8 hrs Skill: Real-Time Sensor Data Overlay

Kit at a glance

What you build: A sensor overlay camera: an ESP32-S3 shows the OV2640 camera image live on a 2.4-inch TFT and draws temperature, humidity (DHT22) and pressure (BMP280) as text on top of the picture, like a heads-up display.

What's in the box

  • ESP32-S3 Dev Board
  • OV2640 Camera Module
  • 2.4in TFT ILI9341
  • DHT22
  • BMP280
  • 4.7kΩ Resistors × 5
  • 100nF Caps × 5
  • PCB Prototype Board × 2
  • 5V 3A PSU
  • Enclosure Box
  • Soldering Iron
  • Solder Wire

Power: 5V 3A adapter included.

Skill level: Advanced (6-8 hours).

Frequently asked questions

Is it real augmented reality?

It's a simple overlay: text drawn on the live image, not objects tracked in 3D.

How smooth is the video?

A few frames a second at TFT size is typical.

With this kit, you’ll build a head-up style display that superposes live environmental readings — temperature, humidity, pressure — directly onto a camera feed, creating a seamless augmented reality experience on a TFT screen. Perfect for prototyping IoT dashboards, industrial monitoring interfaces, and data visualization tools without the complexity of fully custom hardware integration. The ESP32-S3’s dual-core processor handles concurrent image capture and sensor polling, giving you a hands-on lesson in real-time embedded systems.

What You’ll Build

A portable AR overlay system that captures real-time video from the OV2640 camera, reads DHT22 and BMP280 sensors, and draws text overlays of temperature, humidity, and pressure on the TFT display. The system updates instantly, creating a professional-grade monitoring tool that demonstrates sensor fusion and graphic overlay techniques. You’ll end up with a self-contained device ready for field data visualization or a hackathon demo.

What You’ll Learn

  • Real-time sensor data acquisition with I2C and one-wire protocols
  • Camera image capture and framebuffer manipulation on ESP32-S3
  • Overlaying dynamic text and graphics on live video using the TFT_eSPI library
  • Integrating multi-threaded tasks in RTOS for simultaneous sensor polling and display refresh

Kit Contents

Component Quantity
ESP32-S3 Dev Board x1
OV2640 Camera Module x1
2.4in TFT ILI9341 x1
DHT22 x1
BMP280 x1
4.7kΩ Resistors x5
100nF Caps x5
PCB Prototype Board x2
5V 3A PSU x1
Enclosure Box x1
Soldering Iron x1
Solder Wire x1

Who This Kit Is For

Ideal for B.Tech ECE/EEE students tackling final-year projects, Smart India Hackathon participants building rapid prototypes, and researchers at IITs, NITs, VIT, BITS exploring augmented reality interfaces. It’s also a powerful training tool for ATL Tinkering Labs mentors guiding advanced embedded vision work.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

What if I get stuck during the build?

Our AI build companion responds instantly via the QR code on the box, and you can hop on WhatsApp for human backup from the Compoden team.

Can I customize the overlay to display different sensor data or add graphics?

Yes, the codebase is open and structured. You can modify the overlay text, add graphical gauges, or integrate additional I2C sensors easily.

Is this kit suitable for a Smart India Hackathon project?

Absolutely. The kit is designed for rapid prototyping; you can have a functional AR display running in under 8 hours, giving you a strong demo for the hackathon.

What if the camera module has a manufacturing defect?

All components are covered by our 7-day replacement guarantee. Just reach out to support and we’ll ship a replacement immediately.

ESP32-S3 camera + TFT overlays sensor readings as AR text on live camera feed.

What's in this kit

Choose your assembly option:

  • Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
  • Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
