Edge-Detecting Robot Kit: Arduino Uno, 3× TCRT5000, 2WD

SKU: CDN-KIT-2805-CL Brand: Compoden Category: Electronics > Robotics & Motion > Project Kits
Rs. 2,240.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Edge-Detecting Robot Kit: Arduino Uno, 3× TCRT5000, 2WD — a beginner-level kit.

Edge-Detecting Robot Kit: Arduino Uno, 3× TCRT5000, 2WD

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Beginner Build Time: 2-3 hrs Skill: Floor detection logic and motor control

Kit at a glance

What you build: An edge-detecting robot: three TCRT5000 IR sensors under the front see the table surface, and when one looks over the edge an Arduino Uno stops the motors, backs up and turns, so the robot explores a table without falling off.

What's in the box

  • Arduino Uno R3
  • TCRT5000 IR Module × 3
  • L298N Motor Driver
  • TT Gear Motor × 2
  • Castor Wheel
  • 2WD Chassis
  • 18650 Cell × 2
  • 18650 2-Cell Holder
  • 10kΩ Resistors × 10
  • 100nF Caps × 5
  • M-M Wires × 20

Power: two 18650 cells included. A charger is not included.

Skill level: Beginner (3-4 hours, no soldering).

Frequently asked questions

Why three sensors?

Left, centre and right, so it knows which way to turn.

Do dark tables work?

Very dark or shiny tops can fool IR; test first.

Imagine a robot that navigates a tabletop, counting products on a virtual production line—yet never tumbles off the edge. With this kit, makers build precisely that: a wheeled robot with three IR sensors on its underside that detect the table boundary and trigger an immediate motor halt. It’s a perfect introduction to real-world industrial automation, packaged for hands-on learning.

What You'll Build

You’ll assemble a 2-wheel-drive robot with a castor wheel for balance, integrating three TCRT5000 IR modules underneath. When the robot approaches a table edge, the sensors detect the absence of a reflective surface, and the Arduino commands the L298N motor driver to stop both motors instantly—preventing a fall. This mimics factory-floor production counters that rely on edge detection for safety and automation.

What You'll Learn

  • How infrared sensor modules detect reflective surfaces to sense table edges
  • Implementing logic: halt motors immediately when any sensor loses reflection
  • Programming Arduino Uno to read digital sensor inputs and drive the L298N motor controller
  • Assembling a robot chassis, wiring motors and sensors, and managing power with 18650 Li-ion cells

Kit Contents

Component Quantity
Arduino Uno R3 1
TCRT5000 IR Module 3
L298N Motor Driver 1
TT Gear Motor 2
Castor Wheel 1
2WD Chassis 1
18650 Cell 2
18650 2-Cell Holder 1
10kΩ Resistors 10
100nF Caps 5
M-M Wires 20

Who This Kit Is For

This kit is ideal for CBSE students through 10 exploring robotics, for ATL Tinkering Lab sessions, and for hobbyists who want to build a functional robot without soldering. It’s also a great weekend project for B.Tech ECE or EEE students prototyping edge-detection algorithms.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

What if I get stuck during the build?

Our AI build companion guides you step by step through the assembly and code. If you still need help, reach out via WhatsApp—an engineer will respond.

Do I need any prior experience with Arduino?

No, the kit includes beginner-friendly example code and wiring diagrams. Even a first-timer can upload the sketch and see the robot working in a couple of hours.

Can I use this kit for a school exhibition?

Absolutely. The edge-detection logic and production-line theme make it an excellent demonstration of industrial automation and sensor-based control.

Does the kit require soldering?

No soldering is needed. All connections use jumper wires and screw terminals, so no soldering is needed.

Teaches floor detection logic and motor halt.
